Introducing the UCC28C45D PWM Controller from Texas Instruments

The UCC28C45D is a high-performance, BiCMOS pulse-width modulation (PWM) controller from Texas Instruments, designed to cater to a wide range of power supply applications. This versatile chip is an integral component for developers looking to create efficient and reliable power solutions, from switch-mode power supplies to power conversion systems.

Key Features

• High-Frequency Operation: The UCC28C45D operates at a frequency range up to 1MHz, which allows for smaller components, reduced power loss, and compact power supply designs.
• Low Startup and Operating Current: This device boasts a low startup current of 0.5µA and an operating current of 2.5mA, enhancing the overall efficiency of the power system and reducing standby power consumption.
• Improved Efficiency: The controller's features include a totem-pole output stage that can source or sink high peak current, driving power MOSFETs or IGBTs directly, which translates to improved efficiency and faster response times in the power circuit.
• Trimmed Oscillator Discharge Current: This trimming ensures precise duty cycle clamping which is critical for the protection and control of power systems.
• Current-Mode Control: The UCC28C45D employs current-mode control, providing inherent line feed-forward, cycle-by-cycle current limiting, and ease of loop compensation.

Applications

The UCC28C45D is suitable for a variety of applications, including:

• DC-DC Converters
• Off-Line Power Supplies
• AC-DC Adapters and Chargers
• Distributed Power Systems
• Telecom Power Supplies

Reliability and Protection

With built-in features such as undervoltage lockout (UVLO), programmable soft-start, and overcurrent protection, the UCC28C45D ensures safe operation under abnormal operating conditions, making it a reliable choice for critical applications. The device is also available in various package options, including the 8-pin SOIC, providing flexibility for different design needs.

The UCC28C45D from Texas Instruments represents a blend of performance, efficiency, and reliability, making it a solid choice for your power control requirements. Its advanced features enable designers to overcome common challenges in power supply design, ensuring stable and efficient operation across a wide range of applications.
