Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Estimated Pruduction Lead Time 34 Weeks
Features PFC IC Discontinuous (Transition) - SOT-23-6
Manufacturer Texas Instruments
Package Reel - TR
Operating Temperature Range -40°C ~ 125°C (TA)
Mounting Surface Mount
Package SOT-23-6
Case / Package SOT-23-6
Family Name UCC28056
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Part Number 296-UCC28056BDBVTDKR, 296-UCC28056BDBVTTR, 296-UCC28056BDBVTCT
Quantity per package 250
Popularity High
Supply and Demand Status Balance
Win Source Part Number 938063-UCC28056BDBVT
Ultra Librarian 3D Model Ultra Librarian UCC28056BDBVT CAD Model

Description

Introducing the UCC28056BDBVT from Texas Instruments

The UCC28056BDBVT is a cutting-edge power management integrated circuit (IC) designed by Texas Instruments, specifically tailored for non-isolated power supplies. This innovative component is engineered to provide a highly efficient, power factor corrected, and quasi-resonant flyback controller that ensures minimal power loss and enhanced system reliability. It is an ideal choice for designers looking to optimize their power supply solutions in terms of efficiency and performance.

At the heart of the UCC28056BDBVT lies its ability to deliver near-unity power factor by shaping the input current waveform to match the input voltage wave. This feature is crucial for meeting stringent regulatory standards for power consumption and efficiency, making it an environmentally friendly choice for modern electronic applications. The IC is designed to operate over a wide input voltage range, accommodating various global power standards without the need for manual adjustments.

The device comes in a compact SOT-23-6 package, which is perfect for space-constrained applications. Despite its small size, the UCC28056BDBVT does not compromise on performance. It boasts advanced features such as zero current detection and valley-switching capabilities, which enable quasi-resonant operation. This operation mode minimizes switching losses and reduces electromagnetic interference (EMI), thus simplifying the task of meeting EMI compliance.

Additionally, the UCC28056BDBVT is equipped with a suite of protection features that safeguard the power supply and the end application against a range of potential faults. These include overvoltage protection, overcurrent protection, and thermal shutdown. Such protective measures ensure that the power supply can deliver consistent performance over a long operational life, even in the face of abnormal operating conditions.

Whether you're designing power supplies for consumer electronics, home appliances, or office equipment, the UCC28056BDBVT from Texas Instruments is a robust and reliable choice that can help you achieve high efficiency, low standby power, and excellent power factor correction. With its advanced control algorithms and user-friendly features, this IC simplifies the design of energy-efficient power solutions that comply with global energy standards.

For further details and specifications, please refer to the official Texas Instruments datasheets and product documentation.
