The TUSB216IRWBR is a high-performance USB 2.0 High-Speed (HS) signal conditioner, designed to compensate for ISI signal loss in a transmission channel. Manufactured by Texas Instruments, this innovative product is a pivotal component for enhancing signal quality by providing adjustable levels of de-emphasis to downstream devices.

Key Features

• USB 2.0 Compliance: The device is fully compliant with USB 2.0 standards, ensuring seamless integration with existing USB systems and devices.
• Signal Conditioning: It features built-in de-emphasis, which significantly improves signal integrity and extends the reach of USB HS signals.
• Adjustable Equalization: Provides up to 5 levels of input equalization to optimize performance over various physical media.
• Enhanced Electromagnetic Compatibility (EMC): Includes built-in ESD protection and reduces EMI, contributing to the robustness of the design and ease of certification.

Applications

The TUSB216IRWBR is ideal for a range of applications where USB signal integrity may be compromised due to long cable lengths or suboptimal transmission environments. Common applications include:

• Desktop and Laptop Computers
• Docking Stations
• USB Hubs, Peripherals, and Monitors
• Industrial Control Systems
• Consumer Electronics

Technical Specifications

The device is available in a compact QFN-16 package and operates over a temperature range of -40°C to 85°C. It supports a supply voltage range of 3.3V ±10%, making it versatile for various USB-powered devices.

Quality and Reliability

Texas Instruments is known for its commitment to quality, and the TUSB216IRWBR is no exception. It is designed to meet the rigorous demands of modern electronics, ensuring high reliability and performance in any USB application.

For detailed technical information, application notes, and support resources, please visit the Texas Instruments website or contact their support team.
