Products specifications

Categories Integrated Circuits (ICs)
Manufacturer Texas Instruments
Packaging Tube
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 300mV
Data Rate 250kbps
Operating Supply Voltage 3 V ~ 5.5 V
Operating Temperature Range 0°C ~ 70°C
Mounting SMD
Package 16-TSSOP (0.173", 4.40mm Width)
Manufacturer Package 16-TSSOP
Win Source Part Number 1274020-TRS3232ECPW
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Limited
Family Name TRS3232E
Introduction Date August 01, 2003
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian TRS3232ECPW CAD Model

Description

Product Overview: TRS3232ECPW

The TRS3232ECPW is a robust transceiver device from Texas Instruments, designed to facilitate serial communication in a variety of applications. This integrated circuit is part of the TRS3232E line, which is known for providing reliable data transmission while maintaining a low-power consumption profile.

Key Features

  • Interface Type: The TRS3232ECPW is built to support the RS-232 interface standard, ensuring compatibility with a wide range of serial communication protocols.
  • Number of Drivers/Receivers: It comes equipped with 2 drivers and 2 receivers, allowing for full-duplex communication.
  • Supply Voltage: Operating from a single 3.0V to 5.5V power supply, this device is versatile in terms of power requirements, making it suitable for both industrial and commercial environments.
  • Low Power Consumption: With its low-power shutdown mode, the TRS3232ECPW can reduce its power consumption significantly, making it an energy-efficient choice for battery-operated systems.
  • Electrostatic Discharge (ESD) Protection: It features robust ESD protection up to ±15kV, which safeguards the device against the potential damages caused by static electricity.
  • Data Rate: The device supports data rates up to 250 kbps, ensuring swift data transfer for a variety of applications.
  • Temperature Range: It is designed to operate over an industrial temperature range of -40°C to 85°C, providing reliable performance under extreme conditions.

Applications

The TRS3232ECPW is suitable for a range of applications that require reliable RS-232 communications. These include, but are not limited to, point-of-sale (POS) terminals, industrial control systems, telecommunications equipment, and peripheral devices for computers.

Package and Quality

This device is offered in a 20-pin TSSOP (Thin Shrink Small Outline Package) which allows for a compact footprint on printed circuit boards. Texas Instruments ensures high manufacturing standards, providing a product that meets rigorous quality and performance benchmarks.

Ordering Information

To order the TRS3232ECPW or to obtain more information about pricing and availability, please visit the Texas Instruments official website or contact an authorized distributor.
