Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Simple Reset/Power-On Reset
Number of Voltages Monitored 1
Output Open Drain or Open Collector
Reset Active Low
Voltage - Threshold 2V
Temperature Range - Operating -40°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package 6-WSON (1.5x1.5)
Win Source Part Number 1111834-TPS389020DSET
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TPS389020DSET CAD Model

Description

The TPS389020DSET from Texas Instruments is a highly precise voltage supervisor designed to monitor overvoltage and undervoltage conditions, ensuring the reliable operation of microprocessors, microcontrollers, and other voltage-sensitive devices. It is an integral component for systems that require a stringent level of voltage regulation and protection.

Key Features:

  • High Accuracy: This device boasts a high threshold voltage accuracy of ±0.5%, providing dependable monitoring and protection.
  • Low Quiescent Current: With a typical quiescent current of only 1.5 µA, the TPS389020DSET is ideal for battery-powered and low-power applications.
  • Adjustable Threshold: It features an adjustable voltage threshold, allowing for customization to specific system requirements.
  • Manual Reset: A manual reset input is provided, enabling the user to trigger a system reset whenever necessary.
  • Watchdog Timer: An integrated watchdog timer ensures that systems remain responsive and do not lock up without external intervention.
  • Multiple Reset Time Delay Options: The device comes with various reset time delay options, offering flexibility in system design.
  • Temperature Range: It operates over a wide temperature range from -40°C to +125°C, suitable for harsh environments.

Applications:

The TPS389020DSET is versatile and can be used in a variety of applications, including:

  • Portable and battery-powered electronics
  • Industrial control systems
  • Automotive systems
  • Networking and telecommunications equipment
  • Medical devices

Package and Availability:

The device is available in a compact, 6-pin WSON package, making it suitable for space-constrained applications. With Texas Instruments' reputation for quality and reliability, the TPS389020DSET is a trusted choice for designers and engineers seeking a robust voltage supervision solution.

For detailed specifications, application notes, and additional resources, please refer to the official Texas Instruments product page and datasheet for the TPS389020DSET.
