Products specifications

Category Integrated Circuits (ICs)>Power Management (PMIC)>Supervisors
Manufacturer Texas Instruments
Packaging Reel - TR
Type Voltage Detector
Number of Voltages Monitored 1
Voltage - Threshold Adjustable/Selectable
Output Open Drain or Open Collector
Reset Active Low
Reset Timeout 0ms Typical
Temperature Range - Operating -40°C ~ 125°C (TJ)
Mounting Surface Mount
Case / Package SOT-23-6 Thin, TSOT-23-6
Supplier Device Package SOT-23-THIN
Base Product Number TPS3710
RoHS Status ROHS3 Compliant
MSL Level 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Part Number 296-46236-2,296-46236-1,296-46236-6,TPS3710DDCT-ND,2156-TPS3710DDCT,TEXTISTPS3710DDCT
Standard Package 250
Win Source Part Number 1320495-TPS3710DDCT
Ultra Librarian 3D Model Ultra Librarian TPS3710DDCT CAD Model

Description

Overview of Texas Instruments TPS3710DDCT

The Texas Instruments TPS3710DDCT is a high-precision, dual-channel comparator with built-in voltage reference, designed for systems that require ultra-low power consumption and high accuracy. It is well-suited for a wide range of applications, including power management, system monitoring, and portable devices.

Key Features

  • Integrated Voltage Reference: The device includes a 400 mV reference voltage, which provides a stable comparison threshold and reduces external component count.
  • Dual-Channel Comparator: With two independent comparator channels, the TPS3710DDCT can monitor two separate voltage levels simultaneously, making it ideal for multi-level system checks.
  • High Accuracy: The device boasts a tight threshold accuracy of ±0.5%, ensuring reliable operation even in critical applications where precision is paramount.
  • Low Power Consumption: Designed for energy-sensitive applications, the TPS3710DDCT maintains an ultra-low quiescent current of just 5.5 μA, contributing to longer battery life in portable devices.
  • Adjustable Thresholds: While the device includes a built-in reference voltage, it also allows for adjustable voltage thresholds to provide flexibility for various system requirements.
  • Wide Supply Voltage Range: Operating from a supply voltage range of 1.8 V to 18 V, the TPS3710DDCT is versatile and can be used in a broad spectrum of power environments.
  • Push-Pull Outputs: The comparator outputs are push-pull, which eliminates the need for external pull-up resistors and simplifies the interface to downstream digital logic.

Applications

The TPS3710DDCT is ideal for a variety of applications where precision voltage monitoring is required. These include:

  • Battery-powered devices
  • Power supply monitoring
  • Portable consumer electronics
  • Industrial equipment monitoring
  • Automotive systems

Package and Availability

The Texas Instruments TPS3710DDCT comes in a small, surface-mount SOT-23 package, which is suitable for space-constrained applications. It is available for purchase from Texas Instruments and authorized distributors, ensuring easy integration into your design and procurement processes.

With its combination of precision, low power, and dual-channel capability, the TPS3710DDCT from Texas Instruments is an excellent choice for designers looking to enhance system reliability and extend the operational life of their products.
