Products specifications

Categories Integrated Circuits
Manufacturer Texas Instruments
Status Active
Type Hot Swap Controller
Number of Channels 1
Internal Switch(s) Yes
Applications General Purpose
Features Latched Fault, Thermal Limit
Programmable Features Current Limit, OVP, Slew Rate, UVLO
Supply Voltage - Operating 2.7 V to 18 V
Current - Output (Max) 5.3A
Temperature Range - Operating -40°C to 85°C
Operating Supply Current 202μA
Feature Pins DEVSLP, dVdT, EN/UVLO, /FLT, ILIM, IMON, OVP, PGOOD, PGTH
Win Source Part Number 1111553-TPS25940LRVCT
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TPS25940LRVCT CAD Model

Description

Overview of Texas Instruments TPS25940LRVCT

The TPS25940LRVCT is a sophisticated circuit protection and power management device from the industry-leading semiconductor manufacturer, Texas Instruments (TI). This component is specifically designed to enhance the reliability and safety of systems by providing overvoltage, overcurrent, and surge protection. It is an integral part of TI's power protection portfolio and is suitable for a wide range of applications including USB interfaces, consumer electronics, and industrial equipment.

Key Features

  • Adjustable Overvoltage Protection: The TPS25940LRVCT allows for precise setting of overvoltage protection thresholds, ensuring that sensitive components are shielded from potentially damaging voltage spikes.
  • Overcurrent Protection: This device offers fast response to overcurrent events, which helps to prevent damage to the system caused by short circuits or excessive load conditions.
  • Surge Protection: With built-in surge protection, the TPS25940LRVCT can absorb and mitigate transient voltage spikes, thus safeguarding the system against power surges.
  • Power Good (PG) Output: The inclusion of a Power Good output provides real-time feedback on the health of the power supply, enabling system monitoring and diagnostics.
  • Thermal Shutdown: Thermal shutdown functionality is incorporated to protect the device and the system from overheating, which further enhances the overall system reliability.

Applications

The TPS25940LRVCT is versatile and can be used in a variety of applications, such as:

  • USB hubs, peripherals, and chargers
  • Consumer electronics like set-top boxes, TVs, and gaming consoles
  • Industrial control systems
  • Point of sale terminals
  • Enterprise systems where power protection is critical

Package and Quality

Enclosed in a compact VQFN (RVC) package, the TPS25940LRVCT is designed for space-constrained applications. Texas Instruments ensures high standards of quality and reliability, making this product suitable for use in both commercial and industrial environments. As with all TI products, support documentation and design resources are readily available, aiding in the integration of the TPS25940LRVCT into various designs.

With its robust protection features and flexible applications, the TPS25940LRVCT from Texas Instruments represents a reliable solution for advanced circuit protection in modern electronic systems.
