The TPS2556DRBR from Texas Instruments is a sophisticated, adjustable, precision current-limited power switch designed for USB applications. This high-quality integrated circuit (IC) is engineered to provide protection to systems and USB ports by limiting the amount of current that can be drawn by an attached device.

Key Features:

• Adjustable Current-Limit: Users can set the current limit threshold via an external resistor, allowing for precise control over the power supplied to connected devices.
• Reverse Voltage Protection: This device ensures that in the event of a reverse voltage being applied, the system is protected from any potential damage.
• Accurate Current Limiting: The TPS2556DRBR provides a tight tolerance of current limiting, which is essential for protecting sensitive electronic components from excessive current.
• Fast Overcurrent Response: With a quick response time to overcurrent conditions, this power switch helps to prevent damage to both the port and the peripheral device.
• Thermal Shutdown Protection: The IC includes a thermal shutdown feature that disables the power switch to prevent overheating, thereby safeguarding the system.

Applications:

The TPS2556DRBR is suitable for a range of applications, including:

• USB Hubs, Peripherals, and Chargers
• Consumer Electronics
• Portable Devices
• Industrial and Medical Equipment

Technical Specifications:

The device comes in a compact QFN-10 package and operates over a voltage range of 2.5V to 6.5V, making it versatile for various USB power applications. It is also characterized for operation over the free-air temperature range of -40°C to 85°C, ensuring reliable performance under varying environmental conditions.

Quality and Reliability:

Texas Instruments is known for its commitment to quality, and the TPS2556DRBR is no exception. It is designed to meet the rigorous standards of the industry, ensuring both performance and longevity for the end-user's application.

Whether you're developing a new USB application or seeking to enhance an existing design, the TPS2556DRBR offers a robust solution for USB power delivery and protection.
