Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Hot Swap Controller
Number of Channels 1
Applications General Purpose
Features Auto Retry
Programmable Features Current Limit, Fault Timeout, UVLO
Supply Voltage - Operating 9 V to 80 V
Temperature Range - Operating -40°C to 85°C
Operating Supply Current 1mA
Mounting SMD (SMT)
Case / Package 10-VSSOP
Feature Pins EN, PG, PROG, TIMER
Win Source Part Number 033741-TPS2491DGS
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name TPS2491
Introduction Date January 01, 2004
ECCN EAR99
Country of Origin China, Thailand
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian TPS2491DGS CAD Model

Description

Product Overview: TPS2491DGS from Texas Instruments

The TPS2491DGS is a high-performance, integrated circuit designed by Texas Instruments to provide a comprehensive solution for power management applications. This advanced Hot Swap Power Manager is engineered to assist electronic systems in safely handling the insertion and removal of circuit cards into live backplanes or other powered interfaces.

With its robust feature set, the TPS2491DGS is particularly well-suited for telecom and datacom systems, servers, and network equipment, where the maintenance and upgrade of systems without disrupting operation is crucial. The device ensures seamless power control, offering protection to both the system and the user during card insertion and removal.

Key Features:

  • Programmable Current Limit: Users can set the current limit threshold according to their specific application needs, ensuring precise control over the power supplied to the system components.
  • Fast Response Time: The TPS2491DGS reacts swiftly to overcurrent events, providing rapid protection to prevent damage to the system.
  • Under-Voltage Lockout (UVLO): This feature ensures that the device operates only when the input voltage is within an acceptable range, thereby safeguarding the system against low-voltage conditions.
  • Overvoltage Protection: The device includes mechanisms to protect against voltage spikes, further enhancing the safety and reliability of the system.
  • Power Good Output: This signal indicates when the output voltage is within a specified range, providing feedback on the status of the power supply.
  • Thermal Shutdown: In the event of excessive temperature, the TPS2491DGS automatically shuts down to prevent thermal damage.

Physical Characteristics:

The TPS2491DGS comes in a compact 8-pin MSOP (DGS) package, which is ideal for space-constrained applications. Its small footprint allows for integration into a variety of system designs without compromising on performance or functionality.

Applications:

  • Telecom and Networking Equipment
  • Servers and Storage Systems
  • Industrial Control Systems
  • High-Availability Systems

Texas Instruments' commitment to quality and innovation is evident in the TPS2491DGS, making it a reliable choice for designers seeking to enhance the operational safety and efficiency of their power management systems.
