TMS320C6672ACYP

Part No TMS320C6672ACYP
Manufacturer Texas Instruments
Catalog Embedded - DSP (Digital Signal Processors)
Description IC DSP FIX/FLOAT POINT 841FCBGA
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Embedded - DSP (Digital Signal Processors)
Mfr Texas Instruments
Series TMS320C66x
Package Tray
Product Status Active
Type Fixed/Floating Point
Interface EBI/EMI, Ethernet MAC, PCIe, I²C, SPI, SRIO, UART
Clock Rate 1GHz
Non-Volatile Memory ROM (128kB)
On-Chip RAM 5.125MB
Voltage - I/O 1.0V, 1.5V, 1.8V
Voltage - Core 1.00V
Temperature Range - Operating 0°C ~ 85°C (TC)
Mounting Type Surface Mount
Package / Case 841-BFBGA, FCBGA
Supplier Device Package 841-FCBGA (24x24)
Base Product Number TMS320
MSL Level 4 (72 Hours)
REACH Status REACH Unaffected
ECCN 5A991B7
HTSUS 8542.31.0001
Win Source Part Number 1357381-TMS320C6672ACYP
Ultra Librarian 3D Model Ultra Librarian TMS320C6672ACYP CAD Model

Description

The TMS320C6672ACYP from Texas Instruments is a high-performance multicore digital signal processor (DSP) designed to meet the intensive processing demands of modern embedded applications. This DSP is part of the TMS320C66x family of devices, which are known for their fixed and floating-point capabilities, making them suitable for a wide range of applications including telecommunications, imaging, audio, and industrial automation.

Key Features:

  • Core: The TMS320C6672ACYP features a C66x CorePac running at a frequency of up to 1.25 GHz, delivering up to 10 GHz of raw DSP processing power across eight cores.
  • Memory: It is equipped with a robust memory architecture that includes 32KB of L1 program cache, 32KB of L1 data cache per core, and 512KB of L2 cache which can be configured as SRAM for additional flexibility.
  • Interfaces: This DSP offers a range of interfaces such as PCIe, Gigabit Ethernet, and Serial RapidIO, enabling high-speed data transfers and connectivity options for various system requirements.
  • Power Efficiency: Designed with energy efficiency in mind, the TMS320C6672ACYP incorporates advanced power management techniques to optimize performance per watt, crucial for power-sensitive applications.
  • Software Support: Texas Instruments provides a comprehensive software development ecosystem, including the Code Composer Studio IDE, optimized DSP libraries, and real-time operating systems, to accelerate development time.

Applications:

The versatility of the TMS320C6672ACYP makes it ideal for a multitude of applications, such as:

  • Wireless base stations and mission-critical communication infrastructure
  • Medical imaging systems like MRI and CT scanners
  • High-definition video conferencing and broadcasting
  • Audio processing for professional audio systems
  • Industrial control and automation systems

With its powerful multicore architecture, extensive memory and interface options, and comprehensive software support, the TMS320C6672ACYP from Texas Instruments is a formidable choice for developers looking to push the boundaries of digital signal processing in their products.
