The Texas Instruments TLC2252AIDR is a high-precision operational amplifier that offers a perfect blend of power efficiency and accuracy, making it an ideal choice for a wide array of applications. This advanced LinCMOS™ operational amplifier has been designed to work with a single supply voltage that ranges from 2.7V to 16V, or dual supplies of ±1.35V to ±8V.

The TLC2252AIDR comes in a compact SOP-8 package and is characterized by its low input bias current of 1pA typical, which is particularly beneficial in applications where minimal current draw is critical. This feature, coupled with a typical low supply current of 210 μA per channel, allows for its use in battery-powered devices and other power-sensitive applications.

Key Features:

• Low Power Consumption: The device boasts a typical low supply current of 210 μA per channel, which is ideal for battery-operated and portable applications.
• Wide Supply Range: It can operate from a single supply voltage (2.7V to 16V) or dual supplies (±1.35V to ±8V), providing flexibility in various circuit designs.
• High Input Impedance: With an input impedance in the range of tera-ohms, the TLC2252AIDR ensures minimal loading on the input source.
• Low Input Bias Current: The op-amp has a typical input bias current of 1pA, reducing the impact on signal integrity and making it suitable for precision applications.
• Output Rail-to-Rail: The output can swing within a few millivolts of the supply rails, maximizing the dynamic range in single-supply operations.
• Robust ESD Protection: The device is equipped with ESD protection circuitry, safeguarding it against electrostatic discharges.

The TLC2252AIDR operational amplifier is versatile and can be used in a variety of applications, including sensor interfaces, portable instrumentation, analog filters, and many other precision analog circuits. Its combination of features ensures that it maintains signal fidelity and operational performance while minimizing power consumption, making it a reliable choice for designers and engineers looking for a high-performance op-amp solution.

Applications:

• Battery-powered equipment
• Portable instrumentation
• Analog filters
• Data acquisition systems
• Medical instrumentation
• Process control
