Product Overview: Texas Instruments TL431BIDBZT

The Texas Instruments TL431BIDBZT is a precision programmable reference that is designed to offer a reliable solution for voltage regulation in a wide array of electronic applications. This versatile three-terminal adjustable shunt regulator is housed in a small surface-mount package, making it ideal for space-constrained applications.

Key Features

• Voltage Range: Capable of providing an adjustable output voltage from 2.495 V to 36 V with a 0.5% (typical) reference voltage tolerance at 25°C.
• Temperature Stability: Exhibits excellent thermal stability over the entire operating temperature range of -40°C to 125°C, ensuring consistent performance.
• Low Output Noise: Offers a low-output noise characteristic, which is crucial for precision electronics where noise can impact performance.
• High Current Capability: Can handle a continuous sink current capability from 1 mA to 100 mA, making it adaptable for various load conditions.
• Surface-Mount Package: The compact DBZ package allows for efficient use of PCB space and is suitable for automated assembly processes.

Applications

The TL431BIDBZT is a versatile component that can be used in numerous applications, including:

• Power supplies
• Battery chargers
• Voltage monitoring
• Adjustable voltage references
• Switching power supplies

Quality and Reliability

Texas Instruments is renowned for its commitment to quality and reliability, and the TL431BIDBZT is no exception. This shunt regulator is built to meet the stringent requirements of industrial and commercial applications, ensuring long-term stability and performance.

Conclusion

Whether you are designing a sophisticated power supply or need a reliable voltage reference for your circuit, the Texas Instruments TL431BIDBZT offers a blend of precision, flexibility, and durability. Its programmable output voltage and robust design make it an excellent choice for engineers looking for a dependable voltage regulation solution.
