THS7320IYHCT

Part No THS7320IYHCT
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Video Amps and Modules
Description IC AMP FILTER 9DSBGA / Video Amp 3 Filter 9-DSBGA (0.96x0.96)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Linear - Amplifiers - Video Amps and Modules
Mfr Texas Instruments
Package Tape & Reel
Product Status Active
Applications Filter
Output Type Rail-to-Rail
Number of Circuits 3
-3db Bandwidth 20 MHz
Slew Rate 80V/µs
Current - Supply 3.5 mA
Current - Output / Channel 65 mA
Voltage - Supply, Single/Dual (±) 2.6V ~ 5V
Mounting Type Surface Mount
Package / Case 9-XFBGA, DSBGA
Supplier Device Package 9-DSBGA (0.96x0.96)
Base Product Number THS7320
Standard Package 250 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.33.0001
Win Source Part Number 848760-THS7320IYHCT
Ultra Librarian 3D Model Ultra Librarian THS7320IYHCT CAD Model

Description

The THS7320IYHCT from Texas Instruments is a high-performance, low-power, triple video amplifier that is designed to meet the rigorous demands of video processing applications. This versatile amplifier is suitable for a range of products including video broadcasting equipment, surveillance systems, and home entertainment devices.

Key Features

  • Triple Channel: The THS7320IYHCT features three separate video amplifiers, making it ideal for RGB or YPbPr video signal processing.
  • High Bandwidth: With a bandwidth of 8 MHz at a gain of +2, this amplifier is capable of handling high-definition video signals without compromising the quality.
  • Low Power Consumption: The device is designed for power efficiency, which is critical for portable and battery-powered applications.
  • Integrated Filters: It includes fixed gain settings and integrated filters that simplify the design of video systems by reducing the need for external components.
  • Flexibility: The THS7320IYHCT is versatile in its applications, supporting standard definition (SD), enhanced definition (ED), and high definition (HD) video signals.
  • Robustness: This product is built to Texas Instruments' high-quality standards, ensuring reliability and performance in a range of environmental conditions.

Applications

  • Video Broadcasting Equipment
  • Professional Video Editing and Processing
  • Surveillance Systems
  • Home Theater and Entertainment Systems
  • Video Capture and Conversion Devices

Technical Specifications

The THS7320IYHCT operates over a wide supply range of 3.3V to 5V, making it compatible with a variety of digital systems. It is available in a compact 14-pin TSSOP package, ensuring a small footprint on the PCB. The device also features a disable function that reduces power consumption when not in use.

Ordering and Packaging

Each unit of the THS7320IYHCT is meticulously packaged to prevent damage during transport and storage. For ordering, it is important to refer to the specific part number to ensure the correct product configuration is selected.
