Product Overview: SN75ALS176BDRG4

The SN75ALS176BDRG4 is a differential bus transceiver designed by Texas Instruments, which is part of their advanced line of integrated circuits optimized for digital communication networks. Particularly, this device is intended for bidirectional data communication on multipoint bus-transmission lines and is compliant with the TIA/EIA-485-A standard.

Key Features

• Bus-Pin ESD Protection Exceeds 12 kV: The SN75ALS176BDRG4 has been engineered with enhanced electrostatic discharge (ESD) protection on its bus pins, ensuring robust performance in environments where ESD events are likely to occur.
• Combined Differential Driver and Receiver: The device integrates both a differential line driver and a differential input line receiver, making it a versatile solution for balanced data transmission.
• 3-State Driver and Receiver Outputs: With 3-state outputs, this transceiver can be placed in a high impedance state, thus allowing multiple devices to be connected to the same bus without interference.
• Operational Range: It operates over a wide range of supply voltages from 4.5 V to 5.5 V, making it suitable for many applications without the need for additional voltage regulation hardware.

Applications

The SN75ALS176BDRG4 is designed for use in a variety of applications that require robust and reliable data communication. These include, but are not limited to:

• Industrial Control Systems
• Networking Equipment
• Telecommunications Infrastructure
• Data Acquisition Systems

Package and Quality

Encased in an 8-pin SOIC package, the SN75ALS176BDRG4 is designed for space-conscious applications requiring a small footprint. Texas Instruments ensures high manufacturing standards, which means this product is produced with consistent quality, providing reliable performance for critical communication systems.

Environmental and Regulatory Compliance

The SN75ALS176BDRG4 meets or exceeds the requirements of the RoHS directive, making it suitable for use in applications that demand environmentally safe components. Additionally, Texas Instruments' commitment to quality means that this product is manufactured in facilities that adhere to stringent international standards.
