Products specifications

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube
Type Transceiver
Protocol RS422, RS485
Number of Drivers/Receivers 1/1
Duplex Half
Receiver Hysteresis 50mV
Supply Voltage (V) 4.75V ~ 5.25V
Temperature Range - Operating 0°C ~ 70°C
Mounting Style SMD
Manufacturer Package 8-SOIC
Supplier Device Package 8-SOIC
Family Part Number SN75176A
Manufacturer Pack Quantity 75
MSL Level 1 (Unlimited)
Win Source Part Number 1256156-SN75176AD
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Audio, Communications & Networking, Consumer Electronics, Multimedia, Portable Devices
Ultra Librarian 3D Model Ultra Librarian SN75176AD CAD Model

Description

Product Overview: SN75176AD Differential Bus Transceiver

The SN75176AD from Texas Instruments is a robust, high-performance differential bus transceiver designed to meet the stringent requirements of bidirectional data communication on multipoint bus-transmission lines. This device is part of the industry-standard 75176 series and is widely used in applications that require balanced transmission lines, such as RS485 or RS422 networks.

Key Features

  • Compatibility: The transceiver is compatible with the ANSI Standards TIA/EIA-485-A and TIA/EIA-422-B, ensuring reliable communication and interoperability in standardized systems.
  • Bus-Pin Protection: It features protection against high energy spikes on the bus lines, providing a robust solution for industrial environments where electrical noise can be a significant issue.
  • High Speed: Capable of operating at speeds up to 10 Mbps, the SN75176AD is suitable for high-speed data transmission applications.
  • Low Power Consumption: With its low power requirements, this transceiver is an excellent choice for energy-sensitive designs.
  • Wide Operating Temperature: It is designed to function over a broad temperature range, making it suitable for use in extreme environmental conditions.

Applications

The SN75176AD is versatile and can be used in a variety of applications, including:

  • Telecommunications systems
  • Industrial control networks
  • Building automation
  • Security systems

Technical Specifications

The device is offered in an 8-pin SOIC package, with a pinout designed for convenient PCB layout. It operates over a supply voltage range of 4.75V to 5.25V, and features a 3-state driver and receiver output stage, providing the flexibility to disable the device when it is not in use or when multiple transceivers are connected to the same bus.

Quality and Reliability

Texas Instruments is known for its commitment to quality, and the SN75176AD is no exception. It is manufactured to the highest standards to ensure consistent performance and reliability in your application.

For detailed specifications, application notes, and support resources, please refer to the official Texas Instruments documentation available on their website or through authorized distributors.
