Product Description: Texas Instruments SN75174DWR

The SN75174DWR from Texas Instruments is a high-performance, monolithic, low-power Schottky process quad differential line driver designed to meet the requirements of ANSI Standards EIA/TIA-422-B and ITU Recommendation V.11. This device is specifically designed to provide the electrical characteristics necessary to ensure reliable data transmission over long distances.

The SN75174DWR operates from a single 5-V power supply and is supplied in a 20-pin SOIC package. This device features four channels, each comprising an input stage with a three-state output. The three-state outputs enable the drivers to be connected directly to a bus for multi-point applications. The device's outputs are high impedance when disabled or when VCC = 0.

The SN75174DWR features a wide common-mode voltage range, making it suitable for multi-point applications over long cable runs. It also offers thermal shutdown protection, which disables the outputs to prevent damage to the device if the power dissipation becomes excessive.

The SN75174DWR is characterized for operation from 0°C to 70°C. This product is RoHS compliant and is compatible with lead-free soldering techniques. It is also Green Molding Compound (GMC) compliant.

Key Features:

• Meets or Exceeds the Requirements of ANSI Standards EIA/TIA-422-B and ITU Recommendation V.11
• Wide Common-Mode Output Voltage Range
• Thermal Shutdown Protection
• Operates From a Single 5-V Supply
• Low Power Consumption
• Four Channels
• Three-State Outputs
• RoHS Compliant
• Green Molding Compound (GMC) Compliant

In conclusion, the SN75174DWR from Texas Instruments is a robust and reliable solution for your data transmission needs, offering superior performance in a compact, energy-efficient design.
