SN74LVC1G17DCKTE4

Part No SN74LVC1G17DCKTE4
Manufacturer Texas Instruments
Catalog Logic - Buffers, Drivers, Receivers, Transceivers
Description IC BUF NON-INVERT 5.5V SC70-5 / Buffer, Non-Inverting 1 Element 1 Bit per Element Push-Pull Output SC-70-5
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs)>Logic - Buffers, Drivers, Receivers, Transceivers
Mfr Texas Instruments
Series 74LVC
Logic Type Buffer, Non-Inverting
Number of Elements 1
Number of Bits per Element 1
Input Type Schmitt Trigger
Output Type Push-Pull
Current - Output High, Low 32mA, 32mA
Voltage - Supply 1.65V ~ 5.5V
Temperature Range - Operating -40°C ~ 125°C (TA)
Mounting SMD (SMT)
Package / Case 5-TSSOP, SC-70-5, SOT-353
Supplier Device Package SC-70-5
Base Product Number 74LVC1G17
Standard Package 250
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 1259399-SN74LVC1G17DCKTE4
Ultra Librarian 3D Model Ultra Librarian SN74LVC1G17DCKTE4 CAD Model

Description

Product Overview: SN74LVC1G17DCKTE4

The SN74LVC1G17DCKTE4 is a high-performance, single Schmitt-trigger buffer gate designed by the renowned semiconductor manufacturer, Texas Instruments. This device operates on a voltage range of 1.65 to 5.5 V, making it suitable for interfacing with both 3.3V and 5V systems. It belongs to the 74LVC family, which is well-known for its low-voltage operation and low-power consumption.

Key Features

  • Logic Type: Schmitt-trigger buffer gate
  • Supply Voltage Range: 1.65 V to 5.5 V
  • Logic Level Compatibility: LVTTL, LVCMOS
  • Output Drive Capability: ±24 mA at 3.3 V
  • Package: SC70-5
  • Temperature Range: -40°C to 85°C
  • Mounting Type: Surface Mount

Performance and Durability

The SN74LVC1G17DCKTE4 is designed to provide high-speed performance while maintaining the robustness and reliability Texas Instruments is known for. The Schmitt-trigger input provides a hysteresis which enhances noise immunity and allows for slow input transition. This product can handle continuous output currents of up to ±24 mA, enabling it to drive multiple loads simultaneously without performance degradation.

Applications

Due to its versatile nature, the SN74LVC1G17DCKTE4 is widely used in a variety of applications, including:

  • Wave shaping
  • Signal processing
  • Line driving
  • Glitch-free power-up / power-down
  • Interfacing in mixed-voltage environments

Quality and Environmental Compliance

The SN74LVC1G17DCKTE4 is compliant with the RoHS directive, ensuring that it is free from hazardous substances commonly found in electronic components. Texas Instruments' commitment to environmental sustainability and quality is reflected in the rigorous testing and quality control processes that this product undergoes before reaching customers.
