The SN74AXC4T774PWR is a cutting-edge, low-voltage quadruple translating transceiver from Texas Instruments, designed to address the needs of modern high-speed data transmission systems. This device is part of the AXC family, which is known for its low power consumption and high performance, making it suitable for a variety of applications including mobile phones, computing, networking, and industrial markets.

Key Features

• Voltage Level Translation: With dual-supply voltage level translation from 0.65 V to 3.6 V on the A side and 1.2 V to 3.6 V on the B side, the SN74AXC4T774PWR ensures compatibility between devices operating at different voltage levels.
• High-Speed Data Transfer: The device supports high-speed data transfer, with a maximum data rate of 380 Mbps, which is ideal for fast communication protocols.
• Low Power Consumption: The SN74AXC4T774PWR is optimized for low power consumption, which is crucial for battery-powered devices, thereby extending their operational lifespan.
• Wide Operating Temperature Range: It operates over a broad temperature range from -40°C to 85°C, making it robust for industrial applications.

Applications

The versatility of the SN74AXC4T774PWR makes it suitable for a broad range of applications. It can be used in bidirectional level translation for both open-drain and push-pull applications, I2C-bus translation, and as an interface between different logic levels ranging from 0.65 V to 3.6 V.

Package and Quality

The SN74AXC4T774PWR comes in a TSSOP (Thin Shrink Small Outline Package) with 24 pins, providing a compact footprint for space-constrained applications. As with all Texas Instruments products, this transceiver is manufactured to the highest quality standards, ensuring reliability and performance in the field.

Additional Information

For detailed technical specifications, application notes, and support resources, visit the Texas Instruments official website or consult the SN74AXC4T774PWR datasheet. Designers and engineers can also take advantage of Texas Instruments' design tools and community forums for additional support when integrating this transceiver into their projects.
