SN74AVCH24T245NMUR - Texas Instruments

The SN74AVCH24T245NMUR is a state-of-the-art, 24-bit dual-supply bus transceiver from Texas Instruments, designed to facilitate seamless communication between mismatched voltage buses. This component is an integral part of modern digital systems, particularly in applications where data transfer between different voltage domains is required.

Key Features:

• Dual-supply Voltage Operation: The device operates with two distinct supply voltages, V_CCA and V_CCB, which can range from 1.2V to 3.6V, allowing for translation between lower and higher voltage logic levels.
• High-Speed Data Transfer: With the capability to support data rates up to 380 Mbps, this transceiver is suitable for high-speed data transfer applications, ensuring minimal delay and high performance.
• Bus Hold Functionality: The SN74AVCH24T245NMUR is equipped with a bus hold feature that maintains the last known state of the output without needing an external pull-up or pull-down resistor, which helps in preventing floating inputs when no driving signal is present.
• Flow-Through Architecture: The design of the device facilitates easy PCB layout with its flow-through architecture, which simplifies the board design and reduces signal distortion.
• Low Power Consumption: This transceiver is designed for low power consumption, making it an ideal choice for power-sensitive applications.

Applications:

The SN74AVCH24T245NMUR is versatile and can be used in various applications, including:

• Mobile Phones
• Personal Computers
• Networking Equipment
• Telecommunication Infrastructure
• Data Storage

Package and Quality:

Encased in a 56-pin VQFN (RGC) package, the SN74AVCH24T245NMUR is designed for surface mount technology, ensuring a compact footprint on the PCB. Texas Instruments is known for its commitment to quality, and this product is no exception, meeting high standards for reliability and performance.
