The SN74ALS541NSR is a high-quality octal buffer and line driver designed to provide high-speed, low-power performance with true TTL compatibility. Manufactured by Texas Instruments, a leader in semiconductor solutions, this integrated circuit is part of the Advanced Low-Power Schottky (ALS) family, ensuring reliable operation and efficient power consumption.

Key Features

• Logic Type: Octal Buffer/Line Driver, Non-Inverting
• Number of Elements: 1
• Number of Bits per Element: 8
• Output Type: 3-State
• Current - Output High, Low: 2.6mA, 24mA
• Voltage - Supply: 4.5V ~ 5.5V
• Operating Temperature: 0°C ~ 70°C
• Mounting Type: Surface Mount
• Package / Case: 20-SOIC (0.209", 5.30mm Width)

Applications

The SN74ALS541NSR is ideally suited for driving bus lines or buffer memory address registers. Its versatility makes it a good fit for a wide range of applications, including:

• Bus Interface
• Data Communication
• Signal Routing
• Memory Address Driving
• Industrial Control Systems

Quality and Reliability

As with all Texas Instruments products, the SN74ALS541NSR is designed to meet the highest standards of quality and reliability. It is rigorously tested to ensure it meets the stringent requirements for industrial and commercial use, providing designers and engineers with the confidence to integrate this component into their systems.

Environmental Compliance

The SN74ALS541NSR is RoHS compliant, meaning it adheres to the European Union's directive on the restriction of hazardous substances in electronic equipment. This commitment to environmental safety ensures that the product can be used in a variety of markets that demand high environmental standards.
