SN65LBC170DB Real Image SN65LBC170DB Real Image
Same model may have multiple batches, images only for reference.
SN65LBC170DB Real Image SN65LBC170DB Real Image
SN65LBC170DB Real Image SN65LBC170DB Real Image
Same model may have multiple batches, images only for reference.

SN65LBC170DB

Part No SN65LBC170DB
Manufacturer Texas Instruments
Catalog Interface - Drivers, Receivers, Transceivers
Description IC DIFF TRANSCEIVER TRPL 16-SSOP
Datasheet
SN65LBC170DB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Type Transceiver
Protocol RS422, RS485
Number of Drivers/Receivers 3/3
Duplex Half
Receiver Hysteresis 40mV
Data Rate 30Mbps
Supply Voltage - Operating 4.75 V to 5.25 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 16-SSOP
Win Source Part Number 065051-SN65LBC170DB
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SN65LBC170DB CAD Model

Description

The SN65LBC170DB is a high-performance integrated circuit product from Texas Instruments, a renowned global semiconductor design and manufacturing company.

  • TIA/EIA-485 and TIA/EIA-422 Standards: Yes
  • Signaling Rate: Up to 12 Mbit/s
  • Power Supply: Single 5-V
  • Common-Mode Range: -7V to 12V
  • Electrostatic Discharge Protection: Exceeds 12 kV
  • Thermal Shutdown Protection: Yes
  • Enable Function: Yes
  • Package: 38-pin SSOP (DB)
  • Operating Temperature: -40°C to 85°C
