SN54LS14J real image5631
Same model may have multiple batches, images only for reference.

SN54LS14J

Part No SN54LS14J
Manufacturer Texas Instruments
Catalog HOT - SALES and EOL Components (S)
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Texas Instruments
Win Source Part Number 330426-SN54LS14J
Popularity Low
Supply and Demand Status Limited
Package Tube
Product Status Active
Logic Type Inverter
Number of Circuits 6
Number of Inputs 6
Features Schmitt Trigger
Voltage - Supply 4.5 V ~ 5.5 V
Current - Quiescent (Max) 21mA
Current - Output High, Low 400µA, 4mA
Input Logic Level - Low 1V
Input Logic Level - High 1.9V
Max Propagation Delay @ V, Max CL 22ns @ 5V, 15pF
Operating Temperature -55°C ~ 125°C
Grade -
Mounting Type Through Hole
Supplier Device Package 14-CDIP
Package / Case 14-CDIP (0.300\
Ultra Librarian 3D Model Ultra Librarian SN54LS14J CAD Model

Description

The SN54LS14J is a high-performance integrated circuit (IC) produced by Texas Instruments, a renowned global semiconductor company known for its high-quality products.

  • Type: Hex Schmitt-Trigger Inverter.
  • Functionality: Each inverter has a Schmitt trigger circuit designed to provide excellent noise immunity.
  • Operating Voltage Range: Operates over a wide voltage range, from 4.75V to 5.25V.
  • Fan-Out: Features a high fan-out.
  • Technology: Built with low power Schottky technology.
  • Package: Comes in a 14-pin ceramic dual in-line package (DIP).
  • Compliance: RoHS compliant.
