Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Reference Type Series
Output Type Fixed
Nominal Output Voltage (Min/Fixed) 5V
Output Current 21mA
Tolerance ±0.2%
Temperature Coefficient 10ppm/°C
Noise - 0.1Hz to 10Hz 4μVp-p
Voltage - Input 8 V to 40 V
Operating Supply Current 1.4mA
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 088029-REF02BU
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian REF02BU CAD Model

Description

Product REF02BU from Texas Instruments is a high-precision voltage reference device that is designed to deliver a consistent and stable voltage output, regardless of the changes in temperature, load, and time.

  • Voltage Output: Fixed 5-volt output, with an accuracy of ±0.3% @ 25 degrees Celsius
  • Temperature Coefficient: 10 ppm/°C
  • Output Noise: Low output noise of 20 μVp-p
  • Output Current: High output current of 10 mA
  • Output: Short-circuit proof output
  • Dropout Voltage: Low
  • Quiescent Current: Low
  • Package: Small 8-pin SOIC package
