PTN78060WAH

Part No PTN78060WAH
Manufacturer Texas Instruments
Catalog Power Supplies Board Mount DCDC Converters
Description Module DC-DC 1-OUT 2.5V to 12.6V 3A 7-Pin DIP Module Tray / REG SW 2.5-12.6V 3A HORZ T/H
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Texas Instruments
Standard Package 36
Category Power Supplies - Board Mount
Family DC DC Converters
Series PTN78060W
Packaging Tray
Type Non-Isolated PoL Module
Number of Outputs 1
Voltage - Input (Min) 7V
Voltage - Input (Max) 36V
Voltage - Output 1 2.5 ~ 12.6 V
Current - Output (Max) 3A
Applications ITE (Commercial)
Features With UVLO
Mounting Style Through Hole
Package 7-DIP Module
Size / Dimension 1.00" L x 0.62" W x 0.35" H (25.4mm x 15.7mm x 8.9mm)
Operating Temperature Range -40°C ~ 85°C
Efficiency 94%
Power (Watts) - Max 38W
Catalog PTN78060W Series
Win Source Part Number 082101-PTN78060WAH
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Industrial, Automation & Process Control, HVAC, Test & Measurement, Medical, Automotive, Avionics
Family Name PTN78060
Introduction Date December 01, 2005
ECCN EAR99
Country of Origin United States of America
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian PTN78060WAH CAD Model

Description

The PTN78060WAH is a high-performance, integrated circuit (IC) product from Texas Instruments, a renowned global semiconductor company.

  • Series: PTN78060 series
  • Features: Wide-input voltage, adjustable output voltage, and high output current capacity
  • Input Voltage Range: Operates over an input voltage range of 7V to 36V
  • Output Voltage: Output voltage that can be adjusted from 1.2V to 15V
  • Output Current: 3A
  • Efficiency: Up to 96%
  • Protection: Over-temperature and over-current protection
  • Feature: Under-voltage lockout (UVLO)
  • Design: Compact, surface-mount design
  • Compliance: RoHS compliant
