PTN78060WAD

Part No PTN78060WAD
Manufacturer Texas Instruments
Catalog Power Supplies Board Mount DCDC Converters
Description REG SW WIDE-VIN 3A ADJ T/H
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Texas Instruments
Standard Package 36
Category Power Supplies - Board Mount
Family DC DC Converters
Series PTN78060W
Packaging Tray
Type Non-Isolated PoL Module
Number of Outputs 1
Voltage - Input (Min) 7V
Voltage - Input (Max) 36V
Voltage - Output 1 2.5 ~ 12.6 V
Current - Output (Max) 3A
Applications ITE (Commercial)
Mounting Style Through Hole
Package 7-DIP Module
Size / Dimension 1.00" L x 0.62" W x 0.35" H (25.4mm x 15.7mm x 8.9mm)
Operating Temperature Range -40°C ~ 85°C
Efficiency 94%
Power (Watts) - Max 38W
Catalog PTN78060W Series
Win Source Part Number 085135-PTN78060WAD
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian PTN78060WAD CAD Model

Description

The PTN78060WAD is a robust, high-performance, integrated circuit (IC) product from Texas Instruments, a renowned global semiconductor company.

  • Type: 3-A, wide-input adjustable switching regulator
  • Output Voltage: Adjustable and can deliver an output voltage that can be set to any value within the range of 2.5 V to 12.6 V
  • Input Voltage Range: 7 V to 36 V
  • Output Current: High output current up to 3 Amps
  • Efficiency: Highly efficient, with efficiencies up to 96%
  • Protection: Output over-current and over-temperature protection
  • Package: Compact, through-hole, power SIP (single in-line package)
  • Control: Adjustable output voltage and on/off inhibit control
