Products specifications

Category Integrated Circuits (ICs) - Interface - Specialized
Mfr Texas Instruments
Package Tape & Reel
Product Status Last Time Buy
Applications Translating Switch
Interface I2C, SMBus
Voltage - Supply 2.3V ~ 5.5V
Package / Case 16-VFQFN Exposed Pad
Supplier Device Package 16-VQFN (4x3.5)
Mounting Type Surface Mount
Base Product Number PCA9546
Standard Package 3,000 pcs
MSL Level 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 269767-PCA9546ARGYR
Ultra Librarian 3D Model Ultra Librarian PCA9546ARGYR CAD Model

Description

The PCA9546ARGYR is a high-quality, advanced I2C switch from Texas Instruments, a leading global semiconductor company.

  • Description: I2C switch
  • Series: PCA9546A series
  • Voltage Range: 2.3V to 5.5V
  • Switches: Four bidirectional translating switches that can be controlled via the I2C bus and GPIO.
  • Features: Isolates parts of the system, active-low reset input, ability to function with a 3.6V maximum voltage on the SDA/SCL lines even when VCC is at 0V.
  • Package: Compact VQFN (RGR) package of 16 pins
  • Operating Temperature: -40°C to +85°C
  • Data Transfer Rate: High-speed data transfer rate of up to 1 Mbit/s.
  • Modes Supported: Standard mode (Sm), fast mode (Fm), and high-speed mode (Hs)
