PCA9534ADBR Real Image PCA9534ADBR Real Image1 PCA9534ADBR Real Image2
Same model may have multiple batches, images only for reference.
PCA9534ADBR Real Image PCA9534ADBR Real Image1 PCA9534ADBR Real Image2
PCA9534ADBR Real Image PCA9534ADBR Real Image1 PCA9534ADBR Real Image2
Same model may have multiple batches, images only for reference.

PCA9534ADBR

Part No PCA9534ADBR
Manufacturer Texas Instruments
Catalog Interface - I/O Expanders
Description IC I/O EXPANDER I2C 8B 16SSOP
Datasheet
PCA9534ADBR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Number of I/O 8
Interrupt Output Yes
Features POR
Output Type Push-Pull
Current - Output Source/Sink 10mA, 25mA
Max Frequency 400kHz
Supply Voltage - Operating 2.3 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 16-SSOP
Win Source Part Number 026455-PCA9534ADBR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian PCA9534ADBR CAD Model

Description

The PCA9534ADBR is a state-of-the-art product from the renowned global semiconductor design and manufacturing company, Texas Instruments.

  • Product: PCA9534ADBR
  • Manufacturer: Texas Instruments
  • Description: 8-bit I2C and SMBus, low-power I/O (input/output) expander
  • Feature: Interrupt output
  • Interface: Two-wire, bi-directional serial interface
  • Feature: Built-in oscillator
  • Address Recognition: Responds to one hardware address and three software programmable addresses
  • Operating Temperature Range: -40°C to +85°C
  • Power Supply Range: 2.3V to 5.5V
  • Feature: Low standby current
  • Feature: Active LOW reset input
  • Package: Small SSOP (Shrink Small Outline Package) with 16 pins
  • Compliance: RoHS compliant and free from lead, bromine and antimony
