Same model may have multiple batches, images only for reference.
OPA4170AIDR Real Image OPA4170AIDR real image OPA4170AIDR real image4394 OPA4170AIDR real image4395 OPA4170AIDR Real Image1 OPA4170AIDR Real Image2
OPA4170AIDR Real Image OPA4170AIDR real image OPA4170AIDR real image4394 OPA4170AIDR real image4395 OPA4170AIDR Real Image1 OPA4170AIDR Real Image2
Same model may have multiple batches, images only for reference.

OPA4170AIDR

Part No OPA4170AIDR
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP GP 1.2MHZ RRO 14SOIC
Datasheet
OPA4170AIDR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 4
Output Type Rail-to-Rail
Slew Rate 0.4 V/μs
Gain Bandwidth Product (GBP) 1.2MHz
Current - Input Bias 8pA
Voltage - Input Offset 250μV
Operating Supply Current 110μA
Channel Output Current 20mA
Supply Voltage - Operating 2.7 V to 36 V, ±1.35 V to 18 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 14-SOIC
Win Source Part Number 082019-OPA4170AIDR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name OPA4170
Introduction Date August 01, 2011
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian OPA4170AIDR CAD Model

Description

The OPA4170AIDR is a high-end operational amplifier (op-amp) developed and manufactured by Texas Instruments, a globally recognized leader in the field of semiconductor technology.

  • Type: Quad operational amplifier
  • Bandwidth: 5.5MHz
  • Slew Rate: 16V/µs
  • Input Bias Current: 1pA
  • Offset Voltage: 125µV (typical)
  • Input Noise Voltage: 7nV/√Hz
  • Supply Range: 4.5V to 36V
  • Output Swing: Rail-to-rail
  • Temperature Range: -40°C to +125°C
  • Package: 14-pin SOIC package
  • Suitable for: Audio and video processing, sensor interfacing, active filters, and data acquisition systems.
