OPA2340EA Texas Instruments OPA2340EA Real Image1 OPA2340EA Real Image2 OPA2340EA Real Image3 OPA2340EA Real Image4 OPA2340EA Real Image5
Same model may have multiple batches, images only for reference.
OPA2340EA Texas Instruments OPA2340EA Real Image1 OPA2340EA Real Image2 OPA2340EA Real Image3 OPA2340EA Real Image4 OPA2340EA Real Image5
OPA2340EA Texas Instruments OPA2340EA Real Image1 OPA2340EA Real Image2 OPA2340EA Real Image3 OPA2340EA Real Image4 OPA2340EA Real Image5
Same model may have multiple batches, images only for reference.

OPA2340EA

Part No OPA2340EA
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OP AMP GP 5.5MHZ RRIO 8VSSOP
Datasheet
OPA2340EA Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 2
Output Type Rail-to-Rail
Slew Rate 6 V/μs
Gain Bandwidth Product (GBP) 5.5MHz
Current - Input Bias 0.2pA
Voltage - Input Offset 150μV
Operating Supply Current 750μA
Channel Output Current 50mA
Supply Voltage - Operating 2.5 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-VSSOP
Win Source Part Number 089749-OPA2340EA
Family Name OPA2340
Introduction Date January 01, 1995
ECCN EAR99
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Signal Processing, Computers & Computer Peripherals, Test & Measurement, Automation & Process Control, Audio, Communications & Networking
Ultra Librarian 3D Model Ultra Librarian OPA2340EA CAD Model

Description

The OPA2340EA is a high-performance operational amplifier from Texas Instruments, a global semiconductor company that designs, manufactures and sells analog and embedded processing chips.

  • Dual Operational Amplifier: Yes
  • Ultra-Low Input Bias Current: Yes
  • Low Offset Voltage: Yes
  • High-Speed Performance: Yes
  • Supply Range: 2.5V to 5.5V
  • Bandwidth: 5.5MHz
  • Slew Rate: 6V/µs
  • Rail-to-Rail Output Swing: Yes
  • Quiescent Current: 500µA per amplifier
  • Enable/Disable Function: Yes
  • Package: Compact 8-pin SOIC
  • RoHS Compliant: Yes
