NE5532DRG4 Real Image NE5532DRG4 real image NE5532DRG4 label picture
Same model may have multiple batches, images only for reference.
NE5532DRG4 Real Image NE5532DRG4 real image NE5532DRG4 label picture
NE5532DRG4 Real Image NE5532DRG4 real image NE5532DRG4 label picture
Same model may have multiple batches, images only for reference.

NE5532DRG4

Part No NE5532DRG4
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP GP 10MHZ 8SOIC
Datasheet
NE5532DRG4 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 2
Slew Rate 9 V/μs
Gain Bandwidth Product (GBP) 10MHz
Current - Input Bias 200nA
Voltage - Input Offset 500μV
Operating Supply Current 8mA
Channel Output Current 38mA
Supply Voltage - Operating ±5 V to 15 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 140527-NE5532DRG4
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian NE5532DRG4 CAD Model

Description

The NE5532DRG4 from Texas Instruments is a high-performance, low-noise operational amplifier that is designed to deliver superior audio performance.

  • Dual operational amplifier: meaning it has two independent op-amps in a single chip
  • Noise voltage: only 4 nV/√Hz
  • Slew rate: 9V/µs
  • Bandwidth: up to 10 MHz
  • Package: compact 8-pin SOIC package
  • Power supply: operates from a dual power supply
  • Features: short-circuit protection
  • Operating temperature range: -40°C to +85°C
