Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 3/5
Duplex Full
Receiver Hysteresis 500mV
Data Rate 500kbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 28-TSSOP
Win Source Part Number 082991-MAX3243EIPWR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Medical, Imaging, Video & Vision, Automation & Process Control, Portable Devices, Sensing & Instrumentation
Family Name MAX3243E
Introduction Date June 01, 2005
ECCN EAR99
Country of Origin Malaysia, Taiwan
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian MAX3243EIPWR CAD Model

Description

The MAX3243EIPWR is a high-performance product from Texas Instruments, a globally recognized leader in the field of semiconductor technology.

  • Description: 3-V to 5.5-V Multichannel RS-232 Line Driver/Receiver with ±15-kV ESD Protection
  • Operating Voltage: 3.0V to 5.5V
  • Feature: Automatic power-down feature
  • ESD Protection: Up to ±15 kV
  • Package: 28-pin TSSOP package
  • Standby Current: Low
  • Data Rates: Up to 250 kbps
  • Channels: Two drivers and two receivers
