Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 300mV
Data Rate 250kbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 16-TSSOP
Win Source Part Number 021524-MAX3232IPWR
Family Name MAX3232
Introduction Date August 01, 2003
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Industrial, Automotive, Portable Devices, Sensing & Instrumentation, Wireless, Computers & Computer Peripherals
Ultra Librarian 3D Model Ultra Librarian MAX3232IPWR CAD Model

Description

The MAX3232IPWR is a high-performance, dual-driver/receiver from Texas Instruments, a renowned global semiconductor design and manufacturing company.

  • Function: RS-232 to TTL-compatible signals conversion
  • Voltage Range: 3.0V to 5.5V
  • Low-Power Shutdown Mode: Yes
  • Data Rate: 250 kbps
  • ESD Protection (HBM): Exceeds ±15 kV
  • Package: Thin shrink small-outline package (TSSOP)
  • Compliance: RoHS compliant
  • Drivers: 2, ±10V output swing with a 3.0V to 5.5V input
  • Receivers: 2, handles up to ±30V input
