Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 300mV
Data Rate 250kbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 16-TSSOP
Win Source Part Number 082988-MAX3232EIPW
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MAX3232EIPW CAD Model

Description

The MAX3232EIPW from Texas Instruments is a highly efficient, robust, and advanced integrated circuit that is designed to convert signals from an RS-232 interface to signals suitable for use in TTL compatible digital logic circuits.

  • Power Supply: Single 5V
  • Data Signaling Rate: Up to 250 kbit/s
  • ESD Protection (Human-Body Model): 2000-V (JESD 22, A114-A)
  • ESD Protection (Charged-Device Model): 1000-V (JESD 22, C101C)
  • Voltage Range: 3.0 V to 5.5 V
  • Package: 16-pin TSSOP
  • Receivers: 2
  • Drivers: 2
  • Compliance: RoHS compliant
