Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 300mV
Data Rate 250kbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 16-TSSOP
Win Source Part Number 021510-MAX3232ECPWR
Family Name MAX3232E
Introduction Date August 01, 2003
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MAX3232ECPWR CAD Model

Description

The MAX3232ECPWR is a high-performance product from Texas Instruments, a renowned global semiconductor company.

  • Type: Dual driver/receiver with capacitive voltage generator
  • Voltage Supply: Single 3.0-V to 5.5-V
  • Function: Converts TIA/EIA-232-F inputs to 3.0-V to 5.5-V TTL/CMOS levels.
  • Receivers Threshold: Typical threshold of 1.3 V
  • Receivers Hysteresis: Typical hysteresis of 0.5 V
  • Receivers Input: Can accept ±30-V inputs
  • Operation Temp: -40°C to 85°C
  • ESD Protection: Exceeding JESD 22, 2000-V Human-Body Model (A114-A), 200-V Machine Model (A115-A) and 1000-V Charged-Device Model (C101C)
  • Max Data Rate: 250 kbps
  • Package: TSSOP (PW)
