Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 500mV
Data Rate 250kbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 20-SSOP
Win Source Part Number 021478-MAX3223CDBR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MAX3223CDBR CAD Model

Description

The MAX3223CDBR is a high-performing, versatile product from Texas Instruments, a renowned global semiconductor company that designs and manufactures analog ICs and embedded processors.

  • Product: 3-V to 5.5-V Multichannel RS-232 Line Driver/Receiver
  • Operating Voltage: 3.0-V to 5.5-V
  • ESD Protection: ±15-kV
  • Drivers: 2 (guaranteed data rate of 250 kbps)
  • Receivers: 2
  • Auto-Power-Down: Yes (disables driver outputs if no valid RS-232 voltage is present)
  • Standby Mode: Supply current drops to less than 1 µA
  • Package: 28-pin SSOP
  • Temperature Range: -40°C to +85°C
