Products specifications

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 300mV
Data Rate 250kbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 20-TSSOP
Win Source Part Number 021477-MAX3222IPWR
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Industrial, Sensing & Instrumentation
Ultra Librarian 3D Model Ultra Librarian MAX3222IPWR CAD Model

Description

The MAX3222IPWR is a state-of-the-art product from Texas Instruments, a renowned global semiconductor design and manufacturing company.

  • Product: 3-V to 5.5-V Multichannel RS-232 Line Driver/Receiver
  • Interface: TIA/EIA-232-F and V.28/V.24
  • Line Drivers: 2
  • Line Receivers: 2
  • Charge-Pump Circuit: Dual, with ±15-kV ESD protection (pin to pin)
  • Low-Power Consumption: Yes
  • Operating Voltage: 3.0V to 5.5V
  • Automatic Power-Down: Yes
  • Data Signaling Rate: Up to 250 kbps
  • Low-Power Shutdown Mode: 1-µA
  • Package Type: TSSOP
  • RoHS Compliant: Yes
  • Soldering: Lead-free
