Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Manufacturer Texas Instruments
Standard Package 70
Category Integrated Circuits(ICs)
Family Interface - Drivers Receivers Transceivers
Packaging Tube
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 300mV
Data Rate 500kbps
Operating Supply Voltage 3 V ~ 5.5 V
Operating Temperature Range -40°C ~ 85°C
Mounting Style SMD/SMT
Package 20-SSOP (0.209" 5.30mm Width)
Manufacturer Device Package 20-SSOP
Catalog RS-232 Transceivers
Win Source Part Number 073507-MAX3222EIDB
Ultra Librarian 3D Model Ultra Librarian MAX3222EIDB CAD Model

Description

The MAX3222EIDB from Texas Instruments is an advanced electronic component designed to meet the needs of the modern digital world.

  • Product: 3V-powered, multichannel RS-232 line driver/receiver
  • Operating Voltage: 3.0V to 5.5V
  • Package: 16-pin SSOP
  • Low-Power Shutdown Mode: Less than 1uA
  • ESD Protection: ±15kV (RS-232 pins)
  • Standard: Exceeds IEC 61000-4-2
  • Data Rate: 1Mbps
  • Output Stage: Low dropout
  • Receivers: 2 (active in shutdown mode)
  • Drivers: 2
  • Temperature Range: -40°C to +85°C
