Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 1/1
Duplex Full
Receiver Hysteresis 500mV
Data Rate 250kbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 16-TSSOP
Win Source Part Number 082975-MAX3221EIPWR
Family Name MAX3221E
Introduction Date August 01, 2003
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2028
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in RF Communications, Communications & Networking, Motor Drive & Control, Sensing & Instrumentation, Medical, Automation & Process Control
Ultra Librarian 3D Model Ultra Librarian MAX3221EIPWR CAD Model

Description

The MAX3221EIPWR is a robust, high-quality product from Texas Instruments, a renowned global semiconductor company that designs, manufactures, tests, and sells analog and embedded processing chips.

  • Type: Single-channel transmitter and receiver
  • Power Supply: 3.0 to 5.5 V
  • Shutdown Mode Current: 1μA
  • Data Rate: 1Mbps
  • ESD Protection: Up to ±15kV for both Human Body Model (HBM) and IEC61000-4-2 Air-Gap Discharge
  • Package: TSSOP-16
  • Operating Temperature: -40°C to 85°C
