Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 500mV
Data Rate 120Kbps
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 16-SOIC
Win Source Part Number 021355-MAX232IDR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name MAX232
Introduction Date August 01, 2003
ECCN EAR99
Country of Origin Mexico
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian MAX232IDR CAD Model

Description

The MAX232IDR is a high-quality, superior performance integrated circuit (IC) product from Texas Instruments, a leading global semiconductor company known for its innovative and reliable solutions.

  • Operating Temperature: 0°C to 70°C
  • Package: 16-pin SOIC
  • Data Rate: 120 kbps
  • Supply Voltage: 5V
  • ESD Protection: Exceeding JESD 22, 2000-V Human-Body Model (A114-A), 200-V Machine Model (A115-A), and 1000-V Charged-Device Model (C101)
