Products specifications

Manufacturer Texas Instruments
Packaging Reel
Translator Type Voltage Level
Channel Type Bidirectional
Number of Circuits 1
Channels per Circuit 4
Voltage - VCCA 0.8V ~ 4.5V
Voltage - VCCB 1.8V ~ 5.5V
Output Type Open Drain, Push-Pull
Data Rate 100MHz
Temperature Range - Operating -40°C ~ 125°C
Features Auto-Direction Sensing
Mounting Style SMD
Manufacturer Package 14-TSSOP
Supplier Device Package 14-TSSOP
Manufacturer Pack Quantity 2,000
MSL Level 1 (Unlimited)
Popularity High
Supply and Demand Status Sufficient
Win Source Part Number 801691-LSF0204PWR
Ultra Librarian 3D Model Ultra Librarian LSF0204PWR CAD Model

Description

Introducing the LSF0204PWR from Texas Instruments

The LSF0204PWR is a versatile, bidirectional voltage-level translator from the renowned semiconductor manufacturer, Texas Instruments. Designed for multi-voltage digital system applications, this device ensures seamless communication between devices operating at different voltage levels. The LSF0204PWR is an essential component for designers looking to interface low-voltage microprocessors or microcontrollers with higher voltage logic level peripherals.

This innovative level shifter comes in a compact TSSOP (Thin Shrink Small Outline Package) with 14 pins, making it suitable for space-constrained applications. The device provides four bidirectional channels, supporting voltage level translation between 0.95V to 3.6V on the A side (Vref_A pin) and 1.65V to 5.5V on the B side (Vref_B pin). This range of supported voltages makes the LSF0204PWR incredibly versatile and compatible with a wide array of modern digital interfaces.

One of the key features of the LSF0204PWR is its auto-direction sensing capability, which eliminates the need for a direction control signal. Each channel can independently determine the direction of data flow, simplifying the design and reducing the control pin count. This feature is particularly beneficial in applications where pin count is at a premium.

The device also boasts low ON-state resistance, which minimizes signal distortion and ensures high signal integrity. The LSF0204PWR is designed with ESD (Electrostatic Discharge) protection circuitry, safeguarding the device against transient voltage spikes and enhancing system reliability.

For applications requiring level shifting for I2C or SMBus signals, the LSF0204PWR is an excellent choice, as it supports these protocols with its open-drain compatible I/Os. Moreover, the device is also power-off protection enabled, allowing the I/O on each side to be three-stated when the respective supply voltage is removed.

In summary, the LSF0204PWR from Texas Instruments is a highly reliable and efficient solution for voltage level translation in multi-voltage systems. Its ease of use, combined with robust protection features, makes it an ideal choice for a wide range of digital applications including mobile devices, computing, and consumer electronics.
