The LMH1228RTVR is a high-performance Ultra HD-SDI reclocker from Texas Instruments designed to meet the rigorous demands of professional video and broadcast applications. This advanced integrated circuit (IC) is engineered to provide robust signal conditioning and reclocking functionality for 12G-SDI signals, ensuring the integrity of high-bandwidth video data over long cable runs.

Key Features

• Support for High Data Rates: The LMH1228RTVR supports data rates up to 11.88 Gbps, making it suitable for 12G-SDI applications. This includes 4K video at 60Hz with a single cable, streamlining system complexity and reducing cable clutter.
• Advanced Signal Conditioning: The device includes an integrated cable driver and equalizer, allowing it to compensate for signal loss over long cable distances, ensuring high signal integrity and reducing bit error rates.
• Low Power Consumption: Designed with power efficiency in mind, the LMH1228RTVR minimizes power consumption, making it an ideal choice for energy-conscious designs.
• Flexibility: The reclocker is highly versatile, with support for a wide range of video formats and standards, including HD-SDI, 3G-SDI, 6G-SDI, and 12G-SDI.
• Automatic Rate Detection: The LMH1228RTVR automatically detects the SDI rate, simplifying the design and reducing the need for manual configuration.
• Robust Design: The device is offered in a compact WQFN package, ensuring reliability and durability even in space-constrained applications.

Applications

The LMH1228RTVR is ideal for a variety of applications within the broadcasting and professional A/V markets, including:

• Video routers and switchers
• Digital video cameras and recorders
• Video editing and post-production equipment
• Studio-to-transmitter links
• Video distribution amplifiers

Conclusion

The Texas Instruments LMH1228RTVR is a state-of-the-art solution for maintaining signal quality in high-definition video applications. Its combination of high data rate support, signal conditioning capabilities, and low power consumption makes it an essential component for designers looking to create cutting-edge video equipment. Whether for broadcast studios, live event production, or video transport infrastructure, the LMH1228RTVR ensures reliable and high-quality video transmission.
