The ZEN056V130A24LS is a Transient Voltage Suppressor (TVS) diode manufactured by Littelfuse. It is designed to protect sensitive electronic components from voltage transients induced by lightning, electrostatic discharge (ESD), and inductive load switching.

Applications:

• I/O Ports
• Data lines
• Microprocessor protection
• Communication Equipment
• Industrial Control Systems

Features:

• Stand-off Voltage: 56V
• Breakdown Voltage: 62.2V - 68.9V
• Clamping Voltage: 91.3V
• Peak Pulse Current: 24A (8/20μs waveform)
• Package: DO-214AA (SMB)
• Response Time: Typically < 1ps (from 0V to BV min)
• Low Incremental Surge Resistance
• RoHS Compliant

Benefits:

• Effective Transient Protection: Provides robust protection against voltage transients, preventing damage to sensitive electronic components.
• Fast Response Time: Quickly clamps transient voltages, minimizing the risk of damage.
• Low Clamping Voltage: Limits the voltage across the protected circuit to a safe level during transient events.
• Small Package Size: The SMB package allows for easy integration into space-constrained applications.
• High Reliability: Littelfuse's quality manufacturing ensures reliable performance and long-term protection.

Additional Details:

The ZEN056V130A24LS is a TVS diode that utilizes a silicon avalanche technology to provide effective transient voltage suppression. It is designed to protect electronic circuits from damage caused by ESD, EFT, and lightning surges. The SMB (DO-214AA) package provides a small footprint and is suitable for surface mount assembly. The device meets industry standards for transient voltage protection. Its fast response time and low clamping voltage make it an excellent choice for safeguarding sensitive electronic components in a wide range of applications. This part is commonly used in applications requiring compliance with IEC 61000-4-2 (ESD), IEC 61000-4-4 (EFT), and IEC 61000-4-5 (Surge) standards.
