The LM809M3-2.63 is a microprocessor supervisory circuit designed by Texas Instruments to monitor the power supply voltage in digital systems. It serves as a critical component for systems that require a reliable operation, ensuring that the microprocessor and other sensitive digital circuits operate within their specified voltage range. This device is particularly useful in preventing code execution errors during power-up, power-down, and brown-out conditions.

Key Features

• Precision Voltage Monitoring: The LM809M3-2.63 offers precise voltage monitoring of 2.63V, making it ideal for 3V systems and applications where accurate voltage thresholds are crucial.
• Reset Time Delay: It includes a built-in delay feature that provides a reset signal for a minimum of 140ms after power-up to ensure the system has stabilized before the processor begins operation.
• Low Power Consumption: Designed for power-sensitive applications, the LM809M3-2.63 consumes low power, which helps to extend the battery life of portable devices.
• Compact SOT-23 Packaging: The device comes in a small SOT-23 package, making it suitable for space-constrained applications without compromising performance.
• Temperature Range: It operates over a wide temperature range, making it versatile for use in various environmental conditions.

Applications

The LM809M3-2.63 is widely used across various applications that require reliable voltage monitoring and system protection. Some common applications include:

• Portable/Battery-Powered Equipment
• Microcontrollers and Digital Systems
• Computers and Servers
• Embedded Systems
• Industrial Controllers

Quality and Reliability

Texas Instruments is known for its commitment to quality and reliability, and the LM809M3-2.63 is no exception. Each device is rigorously tested to meet the high standards expected from Texas Instruments products, ensuring optimal performance in critical applications.

For detailed technical specifications, application notes, and support resources, customers are encouraged to visit the Texas Instruments official website or contact their support team.
