XB6AD233B Schneider Electric – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

XB6AD233B

Part No XB6AD233B
Manufacturer Schneider Electric
Catalog Pushbutton Switches
Description 16MM PUSH BUTTON, HARMONY XB6, S
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Product Status Obsolete
Mounting Type Panel Mount, Front
Type Standard
Circuit DPST-NO
Switch Function Off-On
Current Rating (Amps) 3A (AC), 220mA (DC)
Voltage Rating - AC 120 V
Voltage Rating - DC 125 V
Actuator Type Square, Button
Color - Actuator/Cap Black
Termination Style Quick Connect - 0.110" (2.8mm)
Ingress Protection IP65 - Dust Tight, Water Resistant
Panel Cutout Dimensions Circular - 16.00mm Dia
Temperature Range - Operating -25°C ~ 70°C
Package Box
Supply and Demand Status Shortage
Win Source Part Number 1559568-XB6AD233B
Ultra Librarian 3D Model Ultra Librarian XB6AD233B CAD Model
