The LM5107MAX/NOPB is a high-performance, feature-rich gate driver designed and manufactured by Texas Instruments. This device is particularly tailored for high-efficiency, high-density power conversion applications. It is capable of driving both the high-side and low-side N-Channel MOSFETs in a synchronous buck or a half-bridge configuration, making it an ideal choice for a wide range of power management solutions.

Key Features

• Voltage Range: The LM5107 is designed to operate over a wide supply voltage range from 8 V to 100 V, which allows for flexible use in various circuit designs.
• Drive Capability: It provides powerful gate drive capability with peak output currents of up to 1.4 A for the high-side and 2 A for the low-side, ensuring rapid charging and discharging of the gate capacitance of large power MOSFETs.
• Adaptive Dead-Time: The built-in adaptive dead-time circuitry helps to prevent shoot-through in the power stage, which enhances the reliability and efficiency of the application.
• Propagation Delays: The device features very low propagation delays and matched internal delays, which allows for precise control of the switching transistors and improved overall system performance.
• Protection Features: It includes under-voltage lockout (UVLO) for both the high-side and low-side drivers, protecting the MOSFETs from operating at insufficient voltages.
• Robustness: The LM5107MAX/NOPB is designed to withstand negative transient voltage, minimizing the need for external components and simplifying design.
• Temperature Range: This device operates over an industrial temperature range from -40°C to 125°C, making it suitable for harsh environments.

Applications

The versatility of the LM5107MAX/NOPB gate driver makes it an excellent choice for a variety of applications, including:

• High-efficiency synchronous buck converters
• Half-bridge and full-bridge converters
• Switched mode power supplies (SMPS)
• Motor control circuits
• Class-D audio amplifiers
• DC-DC converters for telecom and datacom applications

Package and Quality

The LM5107MAX/NOPB is offered in an 8-pin SOIC package, providing a compact footprint for space-constrained applications. The device is also part of Texas Instruments' "NOPB" (No Lead/Ball) series, which means it is lead-free and RoHS compliant, aligning with environmental standards and regulations. The quality and reliability of this gate driver are assured by Texas Instruments' rigorous testing and validation processes.
