LM324MX/NOPB Real Image LM324MX/NOPB real image1344 LM324MX/NOPB Real Image
Same model may have multiple batches, images only for reference.
LM324MX/NOPB Real Image LM324MX/NOPB real image1344 LM324MX/NOPB Real Image
LM324MX/NOPB Real Image LM324MX/NOPB real image1344 LM324MX/NOPB Real Image
Same model may have multiple batches, images only for reference.

LM324MX/NOPB

Part No LM324MX/NOPB
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description Op Amp Quad Low Power Amplifier ±16V/32V 14-Pin SOIC T/R / IC OPAMP GP 1MHZ 14SOIC
Datasheet
LM324MX/NOPB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 4
Slew Rate 0.5 V/μs
Gain Bandwidth Product (GBP) 1MHz
Current - Input Bias 45nA
Voltage - Input Offset 2mV
Operating Supply Current 1.5mA
Channel Output Current 40mA
Supply Voltage - Operating 3 V to 32 V, ±1.5 V to 16 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 14-SOIC
Win Source Part Number 019080-LM324MX/NOPB
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name LM324
Introduction Date December 01, 1994
ECCN EAR99
Country of Origin Malaysia, Philippines
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian LM324MX/NOPB CAD Model

Description

The LM324MX/NOPB is an advanced quad operational amplifier designed by Texas Instruments, a leading global semiconductor company renowned for its advanced analog ICs and embedded processors.

  • Key distinguishing feature: Its low-power consumption, making it highly suitable for battery-powered applications.
  • Voltage Gain: typically around 100 dB
  • Bandwidth: 1.3 MHz
  • Feature: short-circuit protection and its ability to null out offset voltages
  • Input bias and offset currents: very low, making it ideal for applications that require high input impedance
  • Integration: four operational amplifiers in a single package
  • Package: 14-pin SOIC
  • Compliance: RoHS compliant and lead-free
