LM2902DRG4 Texas Instruments LM2902DRG4 Real Image LM2902DRG4 real image
Same model may have multiple batches, images only for reference.
LM2902DRG4 Texas Instruments LM2902DRG4 Real Image LM2902DRG4 real image
LM2902DRG4 Texas Instruments LM2902DRG4 Real Image LM2902DRG4 real image
Same model may have multiple batches, images only for reference.

LM2902DRG4

Part No LM2902DRG4
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP GP 1.2MHZ 14SOIC
Datasheet
LM2902DRG4 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 4
Slew Rate 0.5 V/μs
Gain Bandwidth Product (GBP) 1.2MHz
Current - Input Bias 20nA
Voltage - Input Offset 3mV
Operating Supply Current 1.4mA
Channel Output Current 60mA
Supply Voltage - Operating 3 V to 26 V, ±1.5 V to 13 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 14-SOIC
Win Source Part Number 018924-LM2902DRG4
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LM2902DRG4 CAD Model

Description

The LM2902DRG4 from Texas Instruments is a high-performance, quad operational amplifier that is designed to offer a broad range of features and benefits for a variety of applications.

  • Package: 14-pin SOIC package
  • Operating from a single power supply: 3V to 32V
  • Operating from a dual power supply: ±1.5V to ±16V
  • Key Features: low power consumption.
  • Consumption: 0.7mA per amplifier @ 5V
  • Slew rate: 0.3V/µs
  • Gain-bandwidth product: 1.3MHz
  • Temperature range: from -40°C to 125°C
