LM2759SDX

Name: LM2759SDX
Brand: Texas Instruments
SKU: 182394
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	LM2759SDX
Manufacturer	Texas Instruments
Catalog	PMIC - LED Drivers
Description	IC LED DRVR RGLTR DIM 1A 12WSON
Datasheet	LM2759SDX Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Texas Instruments
Packaging	Reel - TR
Status	Active
Type	DC DC Regulator
Topology	Switched Capacitor (Charge Pump)
Internal Switch(s)	Yes
Number of Outputs	1
Operating Input Voltage(Min)	2.7V
Maximum Supply Voltage	5.5V
Output Voltage	2 V to 4 V
Channel Output Current	1A (Flash)
Frequency	1MHz
Dimming	I2C
Applications	Camera Flash
Temperature Range - Operating	-30°C to 85°C (TA)
Mounting	SMD (SMT)
Case / Package	12-WSON (3x3)
Win Source Part Number	092029-LM2759SDX
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian LM2759SDX CAD Model

Description

The LM2759SDX from Texas Instruments is a highly efficient, advanced and versatile LED driver.

Type: Switch-mode converter.
Operating Mode: Constant frequency, current mode.
LED Support: Up to four white LEDs in parallel.
Output Current: 800mA.
Efficiency: Up to 90%.
Function: Programmable soft-start.
Protection: Programmable over-voltage protection.
Package: Tiny 14-pin WSON.
External Components: Minimal.
Input Voltage Range: 2.7V to 5.5V.
