ISO721MDR Real Image ISO721MDR Real Image
Same model may have multiple batches, images only for reference.
ISO721MDR Real Image ISO721MDR Real Image
ISO721MDR Real Image ISO721MDR Real Image
Same model may have multiple batches, images only for reference.

ISO721MDR

Part No ISO721MDR
Manufacturer Texas Instruments
Catalog Digital Isolators
Description DGTL ISO 2.5KV GEN PURP 8SOIC
Datasheet
ISO721MDR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Channel Type Unidirectional
Isolation Voltage 2500Vrms
Common Mode Transient Immunity (Min) 25kV/μs
Data Rate 150Mbps
Propagation Delay tpLH / tpHL (Max) 16ns, 16ns
Pulse Width Distortion (Max) 1ns
Rise and Fall Time 1ns, 1ns
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Case / Package 8-SOIC
Win Source Part Number 002042-ISO721MDR
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ISO721MDR CAD Model

Description

The ISO721MDR is a high-performance, digital isolator product from Texas Instruments, a leading semiconductor company known for its innovative designs and advanced technology.

  • Isolation for: Power and data lines
  • Isolation Technology: Capacitive isolation technology
  • Data Rate: Up to 150 Mbps
  • Package: Compact, surface-mount SOIC
  • Insulation: Reinforced insulation
  • Safety Standards: UL, CSA, VDE, and CQC
  • Compliance: RoHS compliant
