Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol CAN
Number of Drivers/Receivers 1/1
Duplex Half
Receiver Hysteresis 150mV
Data Rate 1Mbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -55°C to 105°C
Mounting SMD (SMT)
Case / Package 8-SOP
Win Source Part Number 089559-ISO1050DUB
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ISO1050DUB CAD Model

Description

The ISO1050DUB is a high-performance, isolated CAN (Controller Area Network) transceiver manufactured by Texas Instruments, a leading global semiconductor company.

  • Isolation: Up to 5000 Vrms per UL 1577
  • Operating Temperature Range: -40°C to +125°C
  • Feature: Robust transient immunity
  • Feature: Dominant time-out function
  • Bus Fault Protection: Up to ±36 V
  • Standard Compliance: ISO 11898
  • Data Rates: Up to 1 Mbps
  • Power Supply: 5V on one side and a 3.3V or 5V supply on the other side
